Products

DESCRIPTION

Basic Info.

Model NO.	CY-ES30K-H
Max Heating Power	1000W
Heating Method	Infrared Heating Tube
Syringe Capacity	2.5ml~60ml
Max Temperature	Substrate Temperatures up to 60c
Total Power	2.5kw
Input Voltage	0-30kv
Supply Voltage	AC220V/50Hz
Transport Package	Wooden Box
Specification	three sets of collecting devices
Trademark	CYKY
Origin	Zhengzhou, China
HS Code	8514400090
Production Capacity	200 Sets Per Month

Product Description

High-end manufacturing nanofiber electrospinning system for material lab(CY-ES30K-H)High-voltage electrospinning machine(CY-ES30K-H) Introduction:The high-voltage electrospinning machine produced by our company is a device for preparing ultra-fine fibers based on electrospinning technology by using polymer solution or melt to spray in a strong electric field. The machine is mainly composed of four parts: liquid supply device, spinning head, high voltage power supply and collecting device. The liquid supply device adopts a professional scientific research syringe pump, which can provide continuous and stable flow of liquid, and the liquid supply speed can be adjusted to meet the needs of different types of spinning solutions.The spinning head has multiple nozzles and the number of nozzles is optional. The bracket can be adjusted to obtain the best spinning distance and non-woven fabric with different width. The high-voltage power supply can provide long-term stable electric field and the electric field strength for electrospinning is 0-30kV.Equipped with three sets of collecting devices, including a set of six sizes of mandrel collectors for electrospinning; a plate collector for nanofiber collection; and a set of XY-axis movable plate collectors for the preparation of film.High-voltage electrospinning machine application:It can be used in the spinning of a variety of natural or artificial polymeric materials. The films and nanofiber prepared can be used for research and production in various fields such as filtration separation, biomedicine, new energy, and electronic information.Spinning materials:Natural polymers: milk, chocolate, protein, collagen, hydrogel, sodium alginate, cellulose, etc.;Synthetic polymers: hundreds of polymers such as PCL, PLGA, PLLA, nylon, PVDF, PVA, PEO, PAN;Ceramic material: hydroxyapatite, titanium dioxide, tin oxide, silicon oxide, etc.;Composite fiber: carbon fiber, PAN-based, PBI-based, and the like.
Application field:Polluted waste treatment: heavy metal ion adsorption, acid-base water treatment, organic waste gas treatment, organic wastewater treatment, small molecule pollutant adsorption, etc.;Filtration separation: suspended particles, PM2.5 mask, steam engine filter membrane, water filtration, screening, oil-water separation, extraction, seawater desalination, etc.;Biomedicine: drug delivery, dressing, drug extraction, tissue engineering scaffold, bioassay, cosmetics, antibacterial and antibacterial, artificial organs, enzyme immobilization, etc.;New energy: organic solar cells, lithium ion electrode materials, sodium ion battery materials, fuel cells, lithium battery separators, photocatalytic hydrolysis, etc.;Electronic information: gas sensor, humidity sensor, biological detection, flexible circuit, microfluidic chip, micro/nano device, etc.;Catalysis: catalytic treatment of organic waste water, photocatalysis, chemical catalysis, etc.;Defense Military Industry: missile insulation, stealth absorbing, lightweight insulation materials, electromagnetic shielding, etc.;Others: food processing, compound reinforcement, anti-corrosion preservation, waterproof and moisture permeable, aerogel, high temperature insulation, warmth, etc.
High-voltage electrospinning machine technical parameters:

Item		Detail
Supply voltage		AC220V,50Hz
Total power		2.5KW
High voltage power supply	Input voltage	0-30kV
	Max current	0.5mA
Heating source	Heating method	Infrared heating tube
	Max temperature	Substrate temperatures up to 60ºC
	Max heating power	1000W
Syringe pump	Syringe capacity	2.5ml~60ml
	Flow range	2.779μl/min~72.24ml/min
Collector	Mandrel collector	Six sets with various size: 200mm × φ100, 25, 12, 7, 6.0, 2.0mm;Actuator: brushless motor; mandrel shaft speed: 300-4000 rpm; used for electrospinning
	Plate collector	Dimensions: 320mm ×100mm × 2mm; Material: Stainless steel; for nanowire collection
	Y-axis movable plate collector	Dimensions: 300mm × 200mm × 5mm; Material: Stainless steel; used to prepare film, computer program to control the way of moving

High-voltage electrospinning machine detail pictures:

Q. Are you a manufacturer or a trading company?

A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.

Q. How is your company's product after-sales service system?

A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.

Q. How long is your delivery time? If I want to customize the instrument, how long does it take?

A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.

Q. Our country's power supply and plug are different. How do you solve it?

A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.

Q. How to pay?

A.T / T, L / C, D / P, etc., it is recommended to use Alibaba Trade Guarantee.

Q. How is the package of goods? Delivery methods?

A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.

More questions, please contact customer service
